Corn degerming mill

Short Description:

The convex tooth corn degerming  mill series is a coarse crushing equipment used for wet starch production. There are four types of 80/920/1200/1500.


Product Detail

Product Tags

Working Principle
After a grinding process of the socked corn, the crushed corn pieces will fall into the grinding chamber through the inlet under the action of gravity, and then be thrown to the fixed and moving discs. Since the relative rotation of the 2 discs and the special layout of discs, the corn particles will bear a centrifugal force and be thrown out of the discs. In this process, the corn kernels rub and hit with each other to get crushed. While the mutual impact between the particles will have little influence on the corn’s germ, which is good for the separation of germ and reducing the fat content of starch.

It is mainly used for coarse crushing of corn kernels and germ corn kernels after reasonable soaking, so that the germ is separated from dander and endosperm. It is convenient to increase the yield of germ, in order to facilitate the subsequent fine grinding and starch refining. Due to the adjustable spacing, it can also be adapted to the coarse crushing of soybeans after soaking in soy products factory. The machine has simple structure, reliable sealing, stable performance and large output. The maintenance amount is the smallest compared with the same type of equipment, the energy consumption is the lowest, the operation and maintenance are convenient, and the self-protection function is provided.

The main technical parameters

Type Spindle speed(r/min) Maximum adjustable distance of moving plate(mm) Dynamic gear plate and turntable balance requirements
800 Degerm mill 980 60 C≤0.16g
1200 Degerm mill 880 30 C≤0.16g

Type Broken once Broken twice
output Whole corn kernels D-embryo rate Degree of corn breakage Processing capacity Whole corn kernels Germination rate Degree of corn breakage
800 Degerming mill 4-8T Commodity corn/H 1% 85% 4-6 valve 6-8TCommodity corn/H Not allowed 15% 10-12 valve
1200 Degerming mill 20-25T Commodity corn/H 25-30TCommodity corn/H
