Screw press dewatering machine
DLTS series single screw hydro-extractor is equipment adopted mechanical direct pressure method to dehydrate wet material.The dehydrated material can directly enter into the next procedure of drying equipment; it greatly reduces the energy consumption of drying.This machine absorbs the characteristics of similar foreign products, has the characteristics of simple structure, unique design, convenient operation and maintenance. Process performance reaches the advanced level of similar foreign products.
Application
It is widely used in chemical, light industry, food industry etc. such as corn germ, corn fiber and potato residue dehydration in starch industry, etc., to conduct deep processing further, and improve the comprehensive utilization capacity.
Main Specifications & Technical Parameters
| Corn Fiber | Corn Germ | Xanthan Gum | ||||||||
| Specification | 250 | 350 | 500 | 550 | 650 | 250 | 350 | 500 | 550 | 350 |
| Incoming moisture (%) | 85-90 | 75 | / | |||||||
| Outgoing moisture (%) | 60-65 | ≤55 | / | |||||||
| Production capacity before dewatering(kg/h) | 2000-3000 | 3000-5000 | 5000-7000 | 7000-12000 | 12000-15000 | 500-1000 | 800-1500 | 1500-2500 | 2500-3000 | / |
| Power(KW) | 7.5 | 11 | 22 | 30 | 45 | 7.5 | 7.5 | 18.5 | 22 | 4 |
| Overall dimension(L*W*H) | 3725×800×990 | 3690×900×1300 | 5260×1280×1570 | 5735×1280×1690 | 6340×1380×1750 | 3725×800×990 | 3690×900×1300 | 5260×1280×1570 | 5615×1280×1690 | 4400×650×850 |
